WL28

WL28(A01-01) roof trim Diagram

Exploded parts diagram of the roof trim of a Wacker Neuson WL28(A01-01), with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 101000424186Not stocked
    shift console×1
  • 401000350310Not stocked
    lock plug×3
  • 501000238980
    $41.28
    bur strap - 1000238980×0.8
  • 601000027006Not stocked
    blind cover×1
  • 701000272092
    $17.11
    SWITCH FRAME - 1000272092×2
  • 711000521561
    $3.31
    Mounting frame - 1000521561×1
  • 801000272093
    $16.34
    SWITCH FRAME - 1000272093×2
  • 1001000370407Not stocked
    rubber plug×4
