1150 loading bucket Diagram

Exploded parts diagram of the loading bucket of a Wacker Neuson 1150, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

11000154387Not stocked
Bucket (HTF) 2150 mm KRA - 1,15 m³×1
21000017065Not stocked
sleeve×7
31000017066Not stocked
ripper tooth×7
41000161631Not stocked
blade×1
51000003990
$4.71
LOCKING - 1000003990×7
61000037104Not stocked
tooth protection×1
71000031051Not stocked
tension spring×1
81000155020Not stocked
transport hooks×1
91000155052Not stocked
PENDX-1000330311 BUCKET-LT WGHT MAT,91×1
101000115811
$436.14
blade - 1000115811×1
111000037105Not stocked
tooth protection×1
121000154958Not stocked
Super lightw. Bucket 2300mm×1
131000105235
$105.14
Joint 1000105235×1
141000105234
$105.14
Joint 1000105234×1
151000015404Not stocked
hex screw×4
161000021001
$0.89
WASHER - 1000021001×4
171000020788Not stocked
hexagon nut×4
181000096913
$261.04
warning strap - 1000096913×0.564
191000096912
$271.41
WARNING STRAP - 1000096912×0.564
