ET42

ET42 DIPPER ARM Diagram

Exploded parts diagram of the DIPPER ARM of a Wacker Neuson ET42, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000449506Not stocked
    dipperstick×1
  • 21000449507Not stocked
    dipperstick×1
  • 31000374004Not stocked
    o-ring×2
  • 41000388375Not stocked
    steel bushing×4
  • 51000095015
    $1.03
    lock ring - 1000095015×4
  • 61000412105Not stocked
    pin×1
  • 71000015476Not stocked
    grease nipple×3
  • 81000015480Not stocked
    cap grease nipple×3
  • 91000085357
    $1.08
    hex screw - 1000085357×3
  • 101000357535Not stocked
    hexagon nut×3
  • 111000387981Not stocked
    pin×2
  • 121000370166Not stocked
    shim×4
  • 131000491241
    $32.41
    STEEL BUSHING - 1000491241×2
  • 141000015467Not stocked
    lock ring×2
  • 151000453785Not stocked
    pin×1
  • 161000410443Not stocked
    bulk plate×1
  • 171000410442Not stocked
    bulk plate×1
  • 181000094974
    $0.70
    washer M10-DIN134 - 1000094974×4
  • 191000015345
    $1.55
    Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×4
