HI1000
HI1000 Burner cover Diagram
- 475100048456Not stockedPANEL-DOOR,BURNER REAR P-5100021100×1
- 485100048457Not stockedPANEL-DOOR,BURNER,SIDE P-5100021100×1
- 555000180535Not stockedDoor hinge×2
- 565000180578Not stockedBracket×1
- Cable-Ground, 12 AWG, 1/4 Stud - 5200000983×2
- 5015000189215Not stockedHexagonal head cap screw×15
- 5045000192393Not stockedFlat washer×16
- NUT-LOCK M6 HEX. - 5000010368×17
- 5075000167696Not stockedRivet×8
- 5085200001234Not stockedHex screw×16
- 5195000189214Not stockedWasher×6
- SCREW M6 X 60 HX.HD. - 5200000928×2
- CLAMP-HANGER, 2-7/8 - 5200000960×2
- HOLDER-MANUAL, TUBE - 5200000929×1
- 5505000177095Not stockedHexagon nut×13
- 5705200017530Not stockedDoor cpl.×2
- 5735000180577Not stockedGuard×1
- 8375100038780Not stockedWasher×14
