RD24-100CE additive sprinkling Diagram

Exploded parts diagram of the additive sprinkling of a Wacker Neuson RD24-100CE, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

415100013199
$909.19
Bracket - 5100013199×1
425100012458
$52.82
Scraper - 5100012458×4
435100013633
$33.34
Flat steel - 5100013633×3
445100012613
$1.57
Hexagon screw - 5100012613×8
455100012966
$1.57
Locking washer - 5100012966×8
465100013200
$26.41
Metal plate - 5100013200×1
505100012438
$14.53
Silentbloc - 5100012438×1
515100086737Not stocked
fillister head screw×1
525100012965
$3.01
Locking washer - 5100012965×1
535100012545
$1.57
Hexagon nut - 5100012545×1
605100012932
$44.61
Handle - 5100012932×1
615100012665
$1.49
Countersunk screw - 5100012665×2
625100012545
$1.57
Hexagon nut - 5100012545×2
655100013204
$65.25
Jack latch - 5100013204×1
665100034679
$1.66
Washer - 5100034679×2
675100011747
$15.75
Hexagon nut - 5100011747×2
705100012477
$550.56
Sprinkler pipe - 5100012477×1
715100011513
$1.27
Sealing ring - 5100011513×2
735100011514
$11.87
Cap - 5100011514×2
755100011530
$26.46
Nozzle holder - 5100011530Unknown×4
755100011535
$7.59
Cap nut - 5100011535Unknown×1
755100011651
$12.75
Membrane holder - 5100011651Unknown×1
755100073204Not stocked
sealing ring×1
765100066888
$3.71
nut - 5100066888×4
775100011489
$4.80
Filtering screen - 5100011489×4
785100059528
$14.12
sprinkler nozzle - 5100059528×4
795100011978
$4.97
Membrane - 5100011978×4
825100011487
$23.00
Pipe clip - 5100011487×1
835100066888
$3.71
nut - 5100066888×1
855100011553
$18.81
Hose nozzle - 5100011553×1
905100013469
$1.57
Half-clip - 5100013469×4
915100013465
$1.93
Cover plate - 5100013465×2
925100013467
$1.57
Hexagon screw - 5100013467×4
1005100013203
$3,432.45
Scraper - 5100013203×1
1085100012665
$1.49
Countersunk screw - 5100012665×2
1095100033218Not stocked
holder×1
