RD24e-100c

RD24-100CE edge pressing and cuttingdevice Diagram

Exploded parts diagram of the edge pressing and cuttingdevice of a Wacker Neuson RD24-100CE, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 405100073232Not stocked
    edge pressing assembly×1
  • 415100053016Not stocked
    stud screw×4
  • 425100012968
    $1.57
    Locking washer - 5100012968×4
  • 435100012548
    $5.41
    Hexagon nut - 5100012548×4
  • 475100012617
    $2.84
    Hexagon screw - 5100012617×8
  • 485100012967
    $1.57
    Locking washer - 5100012967×8
