TH522
TH522STAGEV fuel injection equipment Diagram
- 11000433786Not stockedfuel pump×1
- 21000433787Not stockedtemperature sensor×1
- sensor - 1000389267×1
- flange - 1000433752×1
- seal - 1000389147×1
- SCREW - 1000130616×2
- seal - 1000389148×1
- gear - 1000433754×1
- pin - 1000225677×2
- plate - 1000433994×1
- nut - 1000433756×1
- Screw - 1000130912×3
- Screw - 1000514012×3
- pipe - 1000389263×1
- pipe - 1000389145×1
- pipe - 1000389144×1
- 161000389276Not stockedPipe×1
- pipe - 1000389143×1
- screw - 1000199433×2
- Bracket - 1000199444×4
- Nut - 1000199519×2
- 211000389140Not stockedpipe line×1
- screw - 1000433788×2
- washer - 1000433790×6
- screw - 1000433789×1
- clamp - 1000433804×2
- 261000389141Not stockedfuel line×1
- 271000433803Not stockedleakoil line×1
- 281000433805Not stockedinjection nozzle×4
- seal - 1000389138×4
- washer - 1000200057×4
- clamp - 1000433807×4
- washer - 1000433802×4
- 331000433996Not stockeddistributor strap×1
- Screw - 1000087301×2
- screw - 1000199433×1
- Pressure Sensor - 1000488845×1
