Excavator 28Z3

28Z3 door Diagram

Exploded parts diagram of the door of a Wacker Neuson 28Z3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000177391
    $3,132.43
    Door 1000177391×1
  • 21000184819
    $14.17
    EZ17 Key without cap - 1000184819×1
  • 31000003865Not stocked
    lock (w/o keys)×1
  • 41000012882
    $49.53
    handle - 1000012882×1
  • 51000052487
    $0.83
    headnut - 1000052487×1
  • 61000069532Not stocked
    synthetic trim×1
  • 71000069533Not stocked
    synthetic trim×1
  • 81000069002Not stocked
    cover lock×1
  • 91000017922Not stocked
    rubber profile×4.2
  • 101000004289Not stocked
    rubber disc×1
  • 111000097240
    $40.71
    sealing profile - 1000097240×4.2
  • 121000165677
    $221.78
    X-1000260288 DOOR WINDOW - 1000165677×1
  • 131000093520
    $2.25
    Washer (Polyamid) - 1000093520×2
  • 141000124883
    $64.26
    Door catch - 1000124883×1
  • 151000018400Not stocked
    hex screw×1
  • 161000094570
    $3.49
    QUAD RING - 1000094570×1
  • 171000012879Not stocked
    quad ring×1
  • 181000082349
    $0.83
    countersunk screw - 1000082349×2
  • 191000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×2
  • 201000172091
    $0.78
    PLUG - 1000172091×2
  • 211000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×1
  • 221000153159
    $24.79
    rubber buffer - 1000153159×1
  • 231000049046Not stocked
    hexagon nut×1
