Excavator 28Z3

28Z3 COVERING/FOPS (Option) Diagram

Exploded parts diagram of the COVERING/FOPS (Option) of a Wacker Neuson 28Z3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000253749
    $3,532.47
    Fopsscreen 1000253749×1
  • 21000015348Not stocked
    hex screw×4
  • 31000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×8
  • 41000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×4
  • 51000067799Not stocked
    cover cap×8
  • 61000253758
    $4,873.98
    Protectingscreen 1000253758×1
  • 71000255488
    $9.06
    cover cap - 1000255488×8
  • 81000015381Not stocked
    hex screw×4
  • 91000241248
    $2.53
    washer - 1000241248×8
  • 101000020127Not stocked
    hexagon nut×4
  • 111000085714
    $19.89
    emergency hammer - 1000085714×1
  • 121000082698
    $0.65
    blind rivet A3x12 - 1000082698×2
  • 131000085715
    $6.86
    bracket emergency hammer - 1000085715×1
  • 141000264714
    $20.92
    DECAL EMERGENCY EXIT - 1000264714×1
  • 151000151228
    $1.03
    cotter pin - 1000151228×1
