Excavator 28Z3

28Z3 fuel tank Diagram

Exploded parts diagram of the fuel tank of a Wacker Neuson 28Z3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000309170
    $784.80
    fuel tank - 1000309170×1
  • 21000307803Not stocked
    Suction lance×1
  • 31000083310
    $2.41
    hose clamp 50-70mm - 1000083310×1
  • 41000262286
    $255.62
    diesel refill hose - 1000262286×1
  • 51000032150Not stocked
    clamp×1
  • 61000168701
    $79.71
    tankfilling - 1000168701×1
  • 71000267866
    $20.53
    FILING STRAINER - 1000267866×1
  • 81000158918
    $67.96
    filler cap - 1000158918×1
  • 91000164459
    $15.74
    CLAMP STRAP - 1000164459×1
  • 101000171327
    $36.54
    RUBBER FOAM - 1000171327×0.84
  • 111000085460
    $0.19
    cheese head screw - 1000085460×4
  • 121000030423Not stocked
    pin×4
  • 131000095343
    $1.42
    washer A 6,4 St A2C DIN9021 - 1000095343×2
  • 141000085588
    $0.32
    self-locking nuts M6-8 A2C-DIN985 - 1000085588×2
  • 151000159940
    $14.78
    CLAMP STRAP - 1000159940×1
  • 161000171327
    $36.54
    RUBBER FOAM - 1000171327×0.9
  • 171000240603
    $19.09
    union nut - 1000240603×1
  • 181000289799
    $5.83
    seal ring - 1000289799×1
