280 cylinder head Diagram

Exploded parts diagram of the cylinder head of a Wacker Neuson 280, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

11000102741
$2,706.04
Cylinder head - 1000102741×1
21000102745
$722.22
bearing support - 1000102745×1
31000102746
$736.69
Cylinderheadcover 1000102746×1
41000005138Not stocked
valve cover seal×1
51000035818
$7.95
headnut - 1000035818×3
61000002921Not stocked
oil filler cap×1
71000085199
$10.73
venting hose - 1000085199×1
81000035757Not stocked
seal ring×1
91000018965
$5.96
O-RING - 1000018965×3
101000085176
$1.82
HEX SCREW - 1000085176×2
111000035806Not stocked
cover×1
121000102747
$3.55
Screen - 1000102747×1
131000035812
$2.78
Seal - 1000035812×1
141000035809
$7.67
PLATE - 1000035809×1
151000085194
$2.80
SCREW - 1000085194×4
161000035694Not stocked
oil pre heater×1
171000098628
$3.76
Seal - 1000098628×1
181000102748
$9.11
Seal - 1000102748×1
191000085197
$2.43
SCREW - 1000085197×1
201000102790
$95.74
suction manifold - 1000102790×1
211000085153
$2.12
SCREW - 1000085153×6
