RD12-90 ROLLER, DOUBLE DRUM, SOLID ROPS
RD12-90 Fuel System Diagram
- ROTOR-INNER - 5000215221×1
- ROTOR-OUTER - 5000215222×1
- FILTER-OIL PUMP - 5000215224×1
- COVER-OIL PUMP - 5000215223×1
- OIL SEAL - 5000215127×1
- O-Ring - 5000215271×1
- PLUG-OIL RELIEF - 5000215226×1
- GASKET-ALUMINUM - 5000215122×1
- SPRING-RELIEF VALVE - 5000215229×1
- BALL-STEEL - 5000215125×1
- OIL GAUGE CPL. - 5000215219×1
- OIL FILLER CAP - 5000215255×1
- Oil fill tube - 5000215220×1
- O-Ring - 5000215225×2
- PIPE-FUEL CPL. - 5000215216×1
- PIPE-RUBBER - 5000215231×1
- CLAMP-HOSE - 5000215234×2
- CARBURETOR CPL. - 5000215206×1
- PIPE-VINYL - 5000215130×1
- Clamp - 5000118053×2
- GASKET-CARBURETOR - 5000215230×1
- PUMP-FUEL CPL. - 5000215244×1
- BRACKET-FUEL PUMP - 5000215227×1
- PIPE-PULSE - 5000215218×1
- X-5000215928-HOSE-RUBBER - 5000215233×1
- CLAMP-HOSE - 5000215234×2
- FILTER-FUEL - 5000206793×1
- PIPE-FUEL CPL. - 5000215217×1
- HOSE-RUBBER - 5000215232×1
- CLAMP-HOSE - 5000215234×2
- BOLT-FLANGE - 5000215228×1
- BOLT-FLANGE - 5000215266×2
- 365000215258Not stockedFlange bolt×4
- NUT-FLANGE - 5000215261×6
