RD25-ROLLER,DOUBLE DRUM
RD25 Rear Frame Diagram
- frame - 5000157316×1
- BAR - 5000157317×1
- BRACKET-RIGHT HANDLE LEVER - 5000157318×1
- NLA HANDLE - 5000157319×1
- chain - 5000157320×1
- CAP-W/KEY - 5000156922×1
- KEY - 5000115556×1
- FILTER-WATER - 5000112582×1
- NLA COVER - 5000157321×1
- GASKET - 5000112884×1
- GUARD - 5000157322×1
- cover - 5000157323×1
- handle - 5000157324×1
- NLA GUARD - 5000157325×1
- bolt - 5000157326×1
- NLA WASHER - 5000113257×1
- NLA WASHER - 5000113259×1
- BUSHING-SHOCK - 5000157327×1
- plate - 5000157328×1
- NLA COVER-HOSE - 5000157944×2
- NLA GUARD - 5000157330×1
- plate - 5000156916×1
- bolt - 5000157331×12
- washer - 5000156919×24
- NUT-LOCK - 5000112808×12
- NLA CLAMP-HOSE - 5000157942×2
- BUSHING-SHOCK - 5000157333×6
- BRACKET-STEP - 5000157350×1
- PLATE-SUPPORT - 5000157334×1
- NLA BOLT - 5000157335×2
- Washer - 5000114465×4
- NUT-LOCK - 5000113471×2
- rod - 5000157336×1
- ROD-CONNECTING - 5000113008×1
- NLA PIN - 5000112729×1
- NLA BOLT - 5000157337×1
- NLA WASHER - 5000157338×1
- NUT-LOCK - 5000112808×1
- NLA BELT - 5000157358×3
- FRAME-FLOOR - 5000157351×1
- REFLECTOR-MIRROR - 5000157352×1
- REFLECTOR-MIRROR - 5000157353×1
- BOLT - 5000112768×2
- Washer - 5000112819×2
- Washer - 5000112828×2
- SPACER - 5000157339×2
- SPACER - 5000157340×2
- NLA BOLT - 5000158584×1
- Nut - 5000113251×1
- RING-LIFT - 5000158585×1
