Excavator 38Z3

38Z3 TRAVELLING GEAR INSTALLATION Diagram

Exploded parts diagram of the TRAVELLING GEAR INSTALLATION of a Wacker Neuson 38Z3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000077391
    $39.15
    SLHYDR 2SC 13 PN15 45 PN15 0 L1000 0 - 1000077391×4
  • 21000076447
    $34.18
    SLHYDR 1SC 6,0PN8 90 PN8 0 L1100 0 - 1000076447×1
  • 31000076495
    $36.09
    SLHYDR 1SC 6,0PN8 90 PN8 0 L1550 0 - 1000076495×1
  • 41000061090Not stocked
    Hose×1
  • 51000076735
    $16.37
    SLHYDR 1SC 8,0PN10 90 PN10 0 L1400 0 - 1000076735×1
  • 61000077407
    $61.55
    SLHYDR 2SC 13 PN15 90 PN15 0 L750,0 0 - 1000077407×2
  • 71000146531
    $86.36
    SLHYDR 2SC 13 PN15 45 PN15 0 L750,0 0 - 1000146531×1
  • 81000146532
    $78.45
    SLHYDR 2SC 13 PN15 45 PN15 0 L650,0 0 - 1000146532×1
  • 91000076376
    $15.19
    SLHYDR 1SCP6,0PN8 0 PN8 90 L1100 0 - 1000076376×2
  • 101000146506
    $45.75
    SLHYDR 1SCP6,0PN8 0 PN8 0 L3400 0 - 1000146506×1
  • 111000065334Not stocked
    Hose×1
  • 121000076334
    $13.81
    SLHYDR 1SCP6,0PN8 0 PN8 90 L850,0 0 - 1000076334×2
