Excavator 38Z3

38Z3 joystick (OPTION) Diagram

Exploded parts diagram of the joystick (OPTION) of a Wacker Neuson 38Z3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000261445
    $365.67
    Joystick 1000261445×2
  • 21000142892Not stocked
    handle×1
  • 31000180747
    $172.11
    HANDLE - 1000180747×1
  • 41000085456
    $0.05
    allen screw M6x20-8.8 A2C-DIN912 - 1000085456×8
  • 51000015436Not stocked
    lock washer×8
  • 61000015430Not stocked
    u-washer×8
  • 71000158213
    $358.14
    PLUNGER KIT - 1000158213×4
  • 81000158212
    $335.50
    PLUNGER KIT - 1000158212×4
  • 91000064799Not stocked
    cross union×2
  • 101000468097Not stocked
    filter×2
  • 111000158227
    $127.69
    bellow - 1000158227×2
  • 121000015488Not stocked
    screw joint×10
  • 131000015574Not stocked
    non return valve×2
  • 141000180749Not stocked
    handle×1
  • 151000068897Not stocked
    adapter plate×1
  • 161000234571
    $130.41
    retrofit kit feeler - 1000234571×2
